Fe140

FE140 is a hard and durable wire designed for use as a stay wire for poles, as well as a top wire and guard wire. With its high tensile strength, it provides stability and long-term reliability, even under demanding conditions. Easy to handle and install, FE140 is a dependable choice for professional infrastructure and power distribution projects. To meet different requirements, it is available in flexible packaging options – supplied either on drums for large-scale installations or on coils for smaller tasks.

Produced in: Sweden

Download Datasheet Request Quotation

Details

Properties

Standards

Conductor

SEN 240804

Product Articles

Name	Cross section	Number of strands	ConsStrandDiameterruction	Total weight	Maximum breaking load
Fe140-25	25 mm²	7	2.12 mm	194 kg/km	33.9 kN
Fe140-33	33 mm²	7	2.44 mm	257 kg/km	44.9 kN
Fe140-52	52 mm²	7	3.08 mm	409 kg/km	71.4 kN
Fe140-68	68 mm²	7	3.52 mm	535 kg/km	93.1 kN
Fe140-89	89 mm²	7	4.02 mm	697 kg/km	122 kN
Fe140-105	105 mm²	7	4.36 mm	820 kg/km	143 kN
Fe140-142	142 mm²	19	3.08 mm	1120 kg/km	194 kN
Fe140-185	185 mm²	19	3.52 mm	1460 kg/km	253 kN
Fe140-241	241 mm²	19	4.02 mm	1910 kg/km	331 kN
Fe140-284	284 mm²	19	4.36 mm	2240 kg/km	390 kN
Fe140-68	68 mm²	7	3.52 mm	535 kg/km	93.1 kN
