AmoSoft G2

AmoSoft G2 is an extra flexible double insulated single core cable. Specially designed for use in industrial applications were extreme flexibility is needed. Suitable for use in short-circuit-proof installations, such as distribution panels and switching devices. AMOSoft G2 and its rare flexibility is one of the easiest products to work with.

Produced in: Sweden

Request Quotation

Details

90°C max

Class 5

Flexible

Halogen-free

Not for direct burial

Properties

Min. temperature	-40 °C
Max temperature	90 °C
AC Voltage rating U₀/U (Uₘ)	0,6/1 (1,2)kv kV
CPR class	Dca

Standards

Conductor	IEC 60228 Class 5
Flame retardant	EN 50575:2014+A1:2016
Halogen free	IEC 60754-1
Material	EN 50363-8
Halogen free	IEC 60754-2
Material	EN 50363-7

Construction

Bending radius - Minimum	4 XOD
Insulation	TPE FR
Outer sheath	TPE FR
Color	Black or customer choice
Labeling example	AmoSoft G2 -size- 0,6/1kV YY/WW CE

Product Articles

Name	Cross section	Outer diameter	Total weight
AmoSoft G2 1X10	10 mm²	8.8 mm	145 kg/km
AmoSoft G2 1X16	16 mm²	9.8 mm	200 kg/km
AmoSoft G2 1X25	25 mm²	11.4 mm	300 kg/km
AmoSoft G2 1X35	35 mm²	12.7 mm	400 kg/km
AmoSoft G2 1X50	50 mm²	14.8 mm	540 kg/km
AmoSoft G2 1X70	70 mm²	16.8 mm	760 kg/km
AmoSoft G2 1X95	95 mm²	18.7 mm	1020 kg/km
AmoSoft G2 1X120	120 mm²	20.9 mm	1210 kg/km
AmoSoft G2 1X150	150 mm²	23.9 mm	1550 kg/km
AmoSoft G2 1X185	185 mm²	26.2 mm	1870 kg/km
AmoSoft G2 1X240	240 mm²	29.7 mm	2410 kg/km
AmoSoft G2 1X300	300 mm²	32.7 mm	2980 kg/km
AmoSoft G2 1X400	400 mm²	36.5 mm	4040 kg/km
